15.6 inch slim 30pin FHD IPS LM156LFCL05 laptop LCD screen
Szczegóły Produktu:
| Miejsce pochodzenia: | Chiny |
| Nazwa handlowa: | PANDA |
| Numer modelu: | LM156LFCL05 |
Zapłata:
| Minimalne zamówienie: | 1 szt |
|---|---|
| Cena: | Negotiable |
| Szczegóły pakowania: | Oryginalne opakowanie/konwencjonalne pudełko do pakowania |
| Czas dostawy: | 7 dni |
| Zasady płatności: | T/T, Western Union |
| Możliwość Supply: | 100000 jednostek/jednostek miesięcznie |
|
Szczegóły informacji |
|||
| Nr modelu: | LM156LFCL05 | Rozmiar przekątnej: | 15,6" |
|---|---|---|---|
| Rezolucja: | 1920 (RGB) × 1080, FHD 141 PPI | Aktywny obszar: | 344,16 (szer.) × 193,59 (wys.) mm |
| Wym. konturu: | 350,66 (wys.) × 216,69 (szer.) × 3,2 (gł.) mm | Leczenie: | Przeciwodblaskowa, Twarda powłoka (3H) |
| Styl formularza: | Wąski (płaski PCBA, T≤3,2 mm) | Zaprojektowany dla: | Laptop |
| High Light: | wymiana lcd laptopa,wymiana ekranu lenovo,wyświetlacz LCD |
||
opis produktu
15.6 inch slim 30pin FHD IPS LM156LFCL05 laptop LCD screen
LM156LFCL05 Product details :
| PANDA LCD Screen LM156LFCL05 (NCP0035) | |
| Brand | PANDA |
| Model | LM156LFCL05 (NCP0035) |
| Diagonal Size | 15.6 inch |
| Type | Oxide TFT-LCD , LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 141PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 344.16(H)×193.59(V) mm |
| Outline Dim. | 350.66(H)×216.69(V)×3.2(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 220 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | FFS, Normally Black, Transmissive |
| Support Color | 262K 45% NTSC |
| Light Source | WLED , 15K hours , With LED Driver |
| Form Style | Slim (PCBA Flat, T≤3.2mm) |
| Designed For | Laptop |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 15.6 inch slim 30pin FHD IPS LM156LFCL05 laptop LCD screen | |
LM156LFCL05 Quality:
We are a professional company, the quality of our products are Grade A+++, without any dead pixels. And all of our products will be tested in real laptops to confirm they will work well before shipping, so you don't need to worry about that.
LM156LFCL05 Payment:
All the following payment methods are aibaba for you. Visa, Master Card, Maestro, American Express, Wire Transfer, Webmoney, Yandex.Money, Western Union, QIWI, DOKU, Mercado Pago, Boleto,bancontact, TEF, iDeal, Giropay, Sofort Banking, Carte Bancaire (Carte Bule), Przelewy24, SMS Payment in Russia (MTC, MegaFon, Beeline, TELE2), Cash Payment (Euroset, Syvaony, Russian Post).
LM156LFCL05 Note:
If failed to pay, please use another credit card, it may be work.
LM156LFCL05 Shipping and Package :
LM156LFCL05 About transportation:
1: The recipient must be the company's full name or full name.
2: If the product ordered is very expensive, you need to get the packaging quickly. It is recommended to use DHL or EMS for transportation.
3: If you choose DHL shipping. Some DHL remote addresses require an additional remote address service fee, approximately $ 35. In some countries, aircraft cannot carry spare batteries. Some motherboards do not have a BIOS battery. You can use the original BIOS battery. I hope you can understand.
4: If a customs clearance fee is incurred, the buyer bears it.
5: After receiving the package, please check the package in time. If the packaging is damaged, save the video evidence. We can ask the logistics company to make up.
LM156LFCL05 Return:
If you receive a damaged or wrong item , please contact us via message , we will arrange return immediately. Please do not leave negative feedback or open any cases before contacting us.
Return is accepted within 30 days after receiving of the item.
When doing the return , please pack the product safely like how we do in the original package. As the screens are very fragile.Please do not use other package.
Buyer is responsible for the return shipping cost in the cases of buyer purchasing wrong products , wrong size ,etc..
LM156LFCL05 FAQ:
Q: Do you accept sample orders for LM156LFCL05 ?
A: Of course!sample order is welcome!
Q: Can you give me a discount if I need a large quantity of PANDA LM156LFCL05 ?
A: Of course!If you make a large order, we will give you a discount.
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of LM156LFCL05 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
